4 Function description
BU 0210 en-3117 47
Pos: 174 /A nleit ung en/El e ktr onik /POS ICON /4. F unk tio nsbes chr eib ung/ Glei c hlauf /Ei nst ellu ng R am penz eit und Ma xim alfr eq wuenz a m Slave @ 14\mod_1478691025699_388.docx @ 2302645 @ 3 @ 1
4.9.2 Ramp time and maximum frequency settings on the slave
In order for the slave to be able to perform the control, the ramp times should be selected somewhat
smaller than for the master and the maximum frequency should be selected somewhat higher.
Slave frequency inverter
Parameter Value
P102
0.5 .. 0,95 * P102
Master
P103 0.5 .. 0,95 * P103
Master
P105
1.05 .. 1.5 * P102
Master
P410 0
P411
P105
Master
Pos: 17 5 /Anlei tu nge n/El ektr oni k/P OSI CON /4. Fun kti ons besc hr eibung / Gleic hla uf/ Eins tel lung Dr ehz ahlr egl er u nd Lager eg ler @ 14\mod_1478694477580_388.docx @ 2302681 @ 3 @ 1
4.9.3 Setting the speed and position controls
1. Set the speed (P300 ff) and position controller (P600 ff) independently of each other in all devices.
2. Commissioning the "Synchronous mode" position control.
The controller settings depend greatly on the characteristics of the drive unit, the drive application and
the load conditions. They can therefore not be planned in advance and must be set or optimised
experimentally on the system.
In principle, better dynamic results can usually be achieved with "sharper" controller settings.
However, for optimum position control, care should be taken that there is a rather moderate setting of
the I-component in the speed controller.
The speed control should be set for a slight overshoot. This results in a P-component which is as high
as possible (until noises occur at low speeds), and a rather moderate I-component..
The setting of the torque limits and the selected ramps must be made so that the drive can always
follow the ramp.
Information
Controller settings
Detailed information about the setting and optimisation of speed and position controllers can be found on our
website www.nord.com in the application guidelines AG 0100 and AG 0101.
