Nord Drivesystems SK 200E Series User Manual

6 Parameters
BU 0210 en-3117 65
P481 Function BusIO Out Bits S
Arrays
[-01] … [-10]
Description
Assignment of functions for Bus IO Out Bits. The Bus IO In Bits are treated as digital
outputs by the frequency inverter.
Setting values
Value Meaning
Pos: 25 3 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/POS ICON/ Saf ety/P 400 bis P4 99 (POS ICON/safety)/P434 / P481 - Funktionen Digitalausgang_Einstellwerte @ 14\mod_1479293302685_388.docx @ 2304814 @ @ 1
0
Off
The output is not used.
20 Reference
Reference point is available / has been saved
21 Position reached
Set position has been reached
22
Comparative position
Position value in
P626
has been reached
23
Comparative position value
Position value in P626 (without consideration of sign) has been
reached.
24 Position array value
A value set in P613 has been reached or exceeded.
25 Comparative position reached
Comparative position has been reached, as for 22, however with
consideration of P625
26
Comparative position value
reached
Comparative position value has been reached, as for 23, however
with consideration of
P625
27 Flying Saw Synchronisation
The slave drive has completed the start phase of the "Flying Saw"
function and is now synchronised with the master axis.
Note: For detailed information about the initial messages see

Section 4.10 "Output messages"
Pos: 25 4 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par amet er/ Par amet erau fli st ung (P 000 .. .)/P 500- P599 /!Zus atz parame ter P5 xx [SK xx xE] @ 9\mod_1447148400288_388.docx @ 262070 @ 3 @ 1
6.1.4 Additional parameters
Pos: 25 5 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/POS ICON/ Saf ety/P 500 bis P5 99 (POS ICON/s afet y)/P502 - Wert Leitfunktion @ 14\mod_1479302610342_388.docx @ 2305199 @ @ 1
P502 Leading function value S P
Arrays
[-01] … [-03]
Description
Assignment of leading functions for the leading values of the master for a
master/slave coupling.
Note
With P503 it must be specified via which bus system the guide value is to be sent to
the slave.
Setting values
Value Meaning
Pos: 25 6 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/POS ICON/ Saf ety/P 500 bis P5 99 (POS ICON/s afet y)/P5 02 / P5 43 - Wert Leit fun kti on_ Eins tell wer te @ 14\ mod_1479303174471_388.docx @ 2305234 @ @ 1
0
Off
The guide value is not used.
6 Actual position Low word Lower 16-bit value of the set position (absolute position) of the
frequency inverter
7
Set position Low word
Lower 16-bit value of the set position (absolute position) of the
frequency inverter
10
Actual position Inc.Low word
Lower 16-bit value of the actual position (relative position) of the
frequency inverter
11 Set pos. Inc.Low word
Lower 16-bit value of the set position (relative position) of the
frequency inverter
12
BusIO Out Bits 0-7
BusIO Out Bits 0-7 of the frequency inverter
13
Actual position High word
Upper 16-bit value of the actual position (absolute position) of the
frequency inverter
14 Set position High word
Upper 16-bit value of the set position (absolute position) of the
frequency inverter
15
Actual position inc. High word
Upper 16-bit value of the actual position (relative position) of the
frequency inverter
16 Setpoint pos. inc. High word
Upper 16-bit value of the set position (relative position) of the
frequency inverter
Pos: 25 7 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/POS ICON/ Saf ety/P 500 bis P599 (POSICON/safety)/P503 - Leitfunktion Ausgabe @ 14\mod_1479713658412_388.docx @ 2305469 @ @ 1
