POSICON positioning control – Supplementary manual for series SK 200E and SK 250E-FDS
74 BU 0210 en-3117
7 Operating status messages
The majority of frequency inverter functions and operating data are continuously monitored and
simultaneously compared with limiting values. If a deviation is detected, the inverter reacts with a
warning or an error message.
Basic information on this topic is contained in the manual for the device.
All faults or reasons which may result in a switch-on block of the frequency inverter and which are
associated with the POSICON function are listed below.
Pos: 32 6 /Anlei tung en/El ektr onik/FU und Star ter/6 . Meld ungen zum Betr iebsz usta nd/Mel dunge n @ 3\mod_1361803071259_388.docx @ 59851 @ 2 @ 1
7.1 Messages
Pos: 32 7 /Anlei tung en/El ektr onik/FU und Star ter/6 . Meld ungen zum Betr iebsz usta nd/Stör mel dung en (Tabel lenü bersc hrift) @ 3\mod_1361803456862_388.docx @ 59874 @ 5 @ 1
Error messages
Display in the
ControlBox
Fault
Text in the ParameterBox
Cause
• Remedy
Group Details in
P700 [-01] /
P701
Pos: 32 8 /Anlei tu nge n/El ektr oni k/P OSI CON /7. Stör ung sm eld ung en/Fe hl er E 013 [PO SIC ON] @ 1 4\mod_1478864423731_388.docx @ 2303169 @ @ 1
E013
13.0 Encoder error
No signal from encoder
• Check 5V sensor if present.
• Check the supply voltage of encoder.
13.1 Speed slip error
"Speed slip error"
The slip speed error limit was reached.
• Increase setting in P327.
13.2 Shut-down monitoring
The slip error shut-down monitoring was triggered; the
motor could not follow the setpoint.
• Check motor data P201-P209! (important for current
controllers)
• Check motor circuit
• Check encoder settings P300 and following in servo
mode
• Increase setting value for torque limit in P112.
• Increase setting value for current limit in P536.
• Check deceleration time P103 and extend if
necessary
13.5 Flying Saw acceleration
"Flying Saw acceleration"
The acceleration path set in P613 [-63] is too small.
13.6 Flying Saw value incorrect
"Flying saw value incorrect"
The prefix of the acceleration path (P613 [-63]) does not
match the prefix of the master drive unit.
Pos: 32 9 /Allg emein/ Allg emeing ültig e Mod ule/---------Sei tenumbr uch ko mpakt --------- @ 13\mod_1476369695906_0.docx @ 2265495 @ @ 1
