4 Function description
BU 0210 en-3117 53
Figure 4: Example of the flaying saw principle
Pos: 18 9 /Allg emein/ Allg emeing ültig e Module/---------Seitenu mbruc h komp akt --------- @ 13\mod_1476369695906_0.docx @ 2265495 @ @ 1
n
Slave
= n
Master
n
Slave
=0
"Synchronise flying saw" output
"Start Flying Saw" input
"Disable synchronous operation" input
P613[-63]
INI – Position = 2 x P613[-63]
Slave standby position (saw)
Starting point of sawing process
Acceleration starts
Brake and return to
starting position
P
Master drive
Slave drive
Initiator:
"Start Flying Saw"
Initiator:
"Disable synchronous operation"
