E014
14.2 Reference point Error
The reference point run was cancelled without a reference
point being found.
• Check the reference point switch and the control unit
14.4 Absolute encoder error
Absolute encoder defective or connection faulty (Error
message is only possible with positioning enabled)
• Check absolute encoder and wiring
• Check the parameterisation in the frequency inverter
• Five seconds after switching on the frequency
inverter there is no contact with the encoder
• The encoder does not respond to an SDO command
from the frequency inverter
• The parameters set in the frequency inverter do not
correspond to the possibilities for the encoder (e.g.
resolution in parameter P605)
• The frequency inverter does not receive a position
value over a period of 50ms
14.5 Pos. diff. Speed
Change of position and speed do not match
• Check the position detection and the setting in P630
14.6 Diff.betw.Abs. & Inc.
Difference between absolute and incremental encoders
• Check the position detection and the setting in P631
• Position change for the absolute and incremental
encoders do not match
• Check the speed ratio or reduction ratio and offset of
both encoders in P607 … P609.
14.7 Max. Pos. Exceeded
Maximum position has been exceeded
• Check the specified setpoint and the control setting
in P615
14.8 Min. Pos. Undershot
Minimum position undershot
• Check the setpoint setting in P616
Pos: 33 5 /Anlei tung en/El ektr onik/FU und Star ter/6 . Mel dung en zum Bet rie bsz ust and /Mel dung en Eins ch alts per re ( Tab ell enü bers chri ft) @ 3\ mod_1361803467385_388.docx @ 59922 @ 5 @ 1
Switch-on block messages
Display in the
SimpleBox /
ControlBox
Reason:
Text in the ParameterBox
Cause
• Remedy
Group Details in
P700 [-03]
Pos: 33 6 /Anlei tung en/El ektr onik/P OSICON /7. Störung smel dung en/Ei nschal tsper re I01 4 [POSIC ON] @ 14 \mod_1478871574871_388.docx @ 2303415 @ @ 1
I014
14.4 Absolute encoder error
Absolute encoder defective or communication interrupted
• Check absolute encoder and wiring
• Check the parameterisation in the frequency inverter
• Five seconds after switching on the frequency
inverter there is no contact with the encoder
• The encoder does not respond to an SDO command
from the frequency inverter
• The parameters set in the frequency inverter do not
correspond to the possibilities for the encoder (e.g.
resolution in parameter P605)
• The frequency inverter does not receive a position
value over a period of 50ms
