POSICON positioning control Supplementary manual for series SK 200E and SK 250E-FDS
64 BU 0210 en-3117
Pos: 25 0 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter /Par a meter aufl ist ung (P 000 ...)/P OSICON /S afety/P 400 bis P4 99 (P OSICON /sa fety)/P 480 - Funkt. BusIO In Bi ts @ 14\mod_1479301643733_388.docx @ 2305129 @ @ 1
P480 Function BusIO In Bits S
Arrays
[-01] … [-12]
Description
Assignment of functions for Bus IO In Bits. The Bus IO In Bits are treated as digital
inputs by the frequency inverter.
Setting values
Value Meaning
Pos: 25 1 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/POS ICON/ Saf ety/P 400 bis P499 (POSICON/safety)/P420 / P480 - Digital ei ng äng e_Eins tel lw erte @ 1 4\mod_1479285521077_388.docx @ 2304534 @ @ 1
0
Off
The input is not used.
22 Reference point run Start of reference point run
( Section
4.2.1.1)
High
23 Reference point Reference point reached
( Section
4.2.1.1)
High
24 Teach-in Start of Teach-in function
( Section
4.4)
High
25
Quit Teach-in
Saving of the actual position
( Section
4.4)
Flank
01
55
Bit 0 PosArr / Inc
Bit 0 Position array / Position increment array
( Section
4.3)
High
56
Bit 1 PosArr / Inc
Bit 1 Position array / Position increment array
( Section
4.3)
High
57
Bit 2 PosArr / Inc
Bit 2 Position array / Position increment array
( Section
4.3)
High
58
Bit 3 PosArr / Inc
Bit 3 Position array / Position increment array
( Section
4.3)
High
59
Bit 4 PosArr / Inc
Bit 4 Position array / Position increment array
( Section
4.3)
High
60
Bit 5 PosArr / Inc
Bit 5 Position array / Position increment array
(
Section 4.3)
High
61
Reset position
Reset of the actual position
(
Section 4.2.1.2)
Flank
01
62
Sync. Position array
Adoption of a preset position
(
Section 4.3)
Flank
01
63
Synchronous operation OFF
With function P610 = 2 "Synchronous operation",
synchronous operation is interrupted, however the
drive unit remains in position control mode. The
position setpoint (P602) of the master drive is reset
with the 0
1 flank. The drive moves back to position
"0" or to the position which is saved in the position
offset (P609) and remains in this position.
High
With function P610 = 5 "Flying Saw", the slave returns
to its starting position and remains there until the next
"Start Flying Saw" command. A new start command is
only accepted if the slave has reached its starting
position. The position setpoint (P602) of the master
drive is reset with the 0
1 flank.
Flank
01
64
Start Flying Saw
Start command for synchronisation of the slave drive
with the master.
( Section
4.9.8)
Flank
01
77
Stop Flying Saw
The "Flying Saw" function is interrupted.
( Section
4.9.8)
Flank
01
78
Trig. remaining path
With function P610 = 10 "Remaining path positioning"
the drive unit switches to position control and moves
for the parameterised "Remaining path".
(
Section 4.8)
Flank
01
Pos: 25 2 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par amet er/ Par amet erau fli st ung (P 000 .. .)/P OS ICON/ S afet y/P 400 bis P49 9 (P OSI CON/ sa fet y)/P 481 - Fun kt. Bus IO O ut Bits ## ### + "saf et y" # ### # @ 1 4\mod_1479302107099_388.docx @ 2305164 @ @ 1
