6 Parameters
BU 0210 en-3117 63
P434 Digital output function P
[-01] … [-02]
Assignment of functions for the digital output
The parameters which are assigned to the output for standardisation (P435) or
hysteresis P436) do not have any effect for the use of functions which are relevant to
POSICON. In this case the hysteresis is set via parameter P625.
Value Meaning
Pos: 24 1 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/POS ICON/ Saf ety/P 400 bis P4 99 (POS ICON/safety)/P434 / P481 - Funktionen Digitalausgang_Einstellwerte @ 14\mod_1479293302685_388.docx @ 2304814 @ @ 1
0 Off
The output is not used.
20 Reference
Reference point is available / has been saved
Set position has been reached
Position value in P626 has been reached
23 Comparative position value
Position value in P626 (without consideration of sign) has been
reached.
A value set in
has been reached or exceeded.
Comparative position reached
Comparative position has been reached, as for 22, however with
consideration of P625
26 Comparative position value
reached
Comparative position value has been reached, as for 23, however
with consideration of
Flying Saw Synchronisation
The slave drive has completed the start phase of the "Flying Saw"
function and is now synchronised with the master axis.
Note: For detailed information about the initial messages see Section
4.10 "Output messages"
