20 Contents
NN10600-175 6.1S2
Figure 139 Steps for making a braided shield 380
Figure 140 Braided shield assembly 381
Figure 141 Cabinet door with hinges on the left 384
Figure 142 Cabinet door with hinges on the right 385
Figure 143 Multiservice Switch cabinet anchoring (concrete and
raised floors) 390
Figure 144 Multiservice Switch 7420 power control 393
Figure 145 Multiservice Switch 7440 power supply 396
Figure 146 The power control on the power supply for a Multiservice
Switch 7460 398
Figure 147 Multiservice Switch cabinet footprint 402
Figure 148 Floor cutout position and size for under floor cable
routing 403
Figure 149 Seismic cabinet footprint 405
Figure 150 Multiservice Switch 7420 termination panel
removal 407
Figure 151 Removing 13” termination panels from the rear of a
Multiservice Switch 7440 409
Figure 152 Door alarm connectors for a Multiservice
Switch 7480 414
Figure 153 Door alarm connector for a Multiservice
Switch 7460 415
Figure 154 Locking and unlocking processor card latches 418
Figure 155 Disengaging a processor card 419
Figure 156 Rack-mounting brackets on Multiservice
Switch 7420 423
Figure 157 Removing vertical mount shelf hardware 424
Figure 158 Removing the feet on a desk-top mounted Multiservice
Switch 7420 425
Figure 159 Cable guide on desk-top mounted Multiservice
Switch 7420 426
Figure 160 Removing the device from a rack 428
Figure 161 Removing the feet from the bottom of a floor-mounted
device 429
Figure 162 Unanchoring a cabinet from a pallet 433
Figure 163 Unloading a cabinet from a pallet 435
Figure 164 Alarm panel for rack-mounted alarm panel kits
NTJS74AA and NTPS20AA 437
Figure 165 Power and alarm panel for rack-mounted alarm panel kit
NTPS20BA 438
