Northern Meditec Taurus E - Selecting Lead; Lead Name and Corresponding Color

文件编号：NR-TP-0715-008 版本：1.0
- 60 -
 Place the electrode on the patient.
 Connect the ECG cable and ECG interface.
Warning
 Check if the lead is normal before monitoring. When the ECG cable is
unplugged, the screen will display [ECG Lead Off] prompt, and trigger an
audible and visual alarm.
12.3.2 Selecting Lead
 Select the ECG parameter area or wave area → [ECGSetup] menu;
 Select [Other Setup >>] → [ECG Other Setup] menu;
 Select [Lead Type], and select the ECG lead as needed:
 [3-Lead]: 3-lead; ECG wave options: I, II, III.
 [5-Lead]: 5-lead; ECG wave options: I, II, III, AVR, AVL, AVF, V.
12.3.3 Lead Name and Corresponding Color
The lead names in European standard and U.S. standard (represented with R, L, N, F, C in
European Standard, and represented with RA, LA, RL, LL, V in the U.S. standard) are shown
in Table 7 -1.
Table 7-1: Lead Name in European Standard and American Standard
European Standard (IEC)
American Standard (AHA)
Lead Name
Color
Lead Name
Color
R
Red
RA
White
L
Yellow
LA
Black
F
Green
LL
Red
N
Black
RL
Green
C
White
V
Brown
