MainTenance anD seRvice
6 Make sure that in particular the measurement surface with the inductive coil and the three
optical sensors [Fig. 15/1] and the runway [Fig. 15/2]ontheightdeckareclean.Incase
these areas are not clean, repeat steps 4 and 5 and check again for cleanliness.
7 Closeightdeckandpressclosingdevice[Fig. 14/2]sothattheightdeckaudiblyclicks
into place.
8 Reconnect the machine to the mains supply.
1
Fig. 14: Openingandclosingtheightdeckofthecoinvalidator
2
Fig. 15: Areas and parts to be cleaned in the measurement and validation area
1
2
