＜List of H group functions＞
Ｈ№
Name & Set range
（Initial value is underlined）
Change
during
driving
Record
of set
value
H00
Selection of functions of IN1 input
0:Driving with High input
1:Driving with Low input (reverse)
2:Separate IN1 (reverse) from
driving condition
3:Separate IN1 from driving condition
4:Control P1 with IN1 (reverse)
5:Control P1 with IN1
6:
Use IN1 as ON delay timer 1 input
and use IN2 as OFF delay timer 1
input
7:
Use IN1 (reverse) as ON delay
timer 1 input and use IN2 as OFF
delay timer 1 input
Can
H01
ON delay timer 1
0.0
~60.0 (Sec.)
Can
H02
OFF delay timer 1
0.0
~30.0(Sec.)
Can
H03
Selection of functions of IN2 input
Selection of functions of IN1 input
0:Timer 2 operates with Low input
1: Timer 2 operates with High input
2: Operate timer 2 with IN1 input,
and output the result on P2
3: Operate timer 2 with reverse
signal of IN1 input, and output
the result on P2
4: Control timer 2 with IN1 input,
and output the result on P2.
Use timer 2 as one shot timer.
Can
H04
ON delay timer 2
0.0
~60.0(Sec.)
Can
H05
OFF delay timer 2
0.0
~30.0(sec.)
Can
＊Initial value of ECH45.
Ｈ№
Name & Set range
（Initial value is underlined）
Change
during
driving
Record
of set
value
H06
Soft start time
0.0~5.0(Sec.) Initial value 0.5
Can
H07
Soft stop time
0.0~5.0(Sec.) Initial value 0.3
Can
H08
Use of work shortage timer
0: Not used
1:Detected by IN1 signal
2:Detected by IN2 signal
Can
H09
Work shortage detection time
1.0~120.0(Sec.)
Initial value 10.0
Can
H10
Work shortage reset time
0.1~30.0(Sec.)
Initial value 1.0
Can
H11
Multi speed input switching
0:Switching with signals of B1
and B2 terminals
1:Control speed with A1 input
Can
not
H12
Frequency of speed 1
30.0~500.0(Hz)
Initial value 140.0
(70.0)
*
Can
H13
Voltage of speed 1
0~200(V)
Initial value 100
Can
H14
Frequency of speed 2
30.0~500.0(Hz)
Initial value 140.0
(70.0)
*
Can
H15
Voltage of speed 2
0~200(V)
Initial value 100
Can
H16
Frequency of speed 3
30.0~500.0(Hz)
Initial value 140.0
(70.0)
*
Can
H17
Voltage of speed 3
0~200(V)
Initial value 100
Can
