Display Name Content
J02 Selection of driving method
Initial value: 1
The input condition of the driving ON/OFF signal is switched.
External control terminal: X1 terminal
Overflow detection sensor input: IN1 or IN2 terminal
0: Driving by AND with the external control terminal signal and the overflow
detection sensor (Both conditions must be on the driving sides). (X1
open: Driving)
1: Driving by AND with the reversed logic of the external control terminal
signal and the overflow detection sensor (Both conditions must be on the
driving sides). (X1 open: Stopping)
2: Driving/stopping by RUN/STOP keys of the operation panel
3: Driving by AND with the operation panel RUN/STOP keys and the
overflow detection sensor.
Even during panel locking, the RUN/STOP key is effective when the panel
control has been selected.
It is not possible to get the ON/OFF delay timer to work with the external
control terminal signal.
J03 Selection of JOG driving
Initial value: 0
Even when the driving is stopping by the external control (J02 is 0 or 1), it is
possible to drive compulsorily only while the RUN button of the operation
panel is being pressed
. Please use it at the initial supply of the work or
discharging or at the time of adjustment. The JOG lamp (green) on the side of
the RUN button lights when JOG drive can be done.
0：JOG driving function is not used
1：JOG (compulsory single) driving function is used.
Even if a knob lock or the operation lock is set, the JOG driving is effective.
J04 Setting of F-V curve
Initial value:
ECF25⇒F
ECH45⇒H
Unchangeable during driving
The F/V curve is set according to the main body used.
Data can be changed only while driving is stopping
. Please surely confirm the
setting before driving. When the setting is mistaken, the accident such as
burning of the magnet will occur.
As the data setting changes with the main body used, set it to an appropriate
value with surely reading P.38, when you change the data of the F/V curve.
F: Selection of curves of full wave system such as N25
H: Selection of curves of half wave system such as S30
C: Selection of curves of high frequency system such as HF10
0～17: Specifying directly of curve №
＊When you use № 0-17, please examine the characteristic of the load
current and set it after investigations not so as to get overloaded.
＊When a special specification such as S10, S20, N25-1 is driven by half
wave, please select also the full wave for the F/V curb.
J05 Not used This function cannot be used.
J06 Not used This function cannot be used.
J07 Not used This function cannot be used.
J08 Selection of terminal AL1 function
Initial value: 0
The signal given to the output terminal AL1 is selected.
0: When the work shortage warning comes out, the output is turned ON.
1: When the overload warning (OL blinking) comes out, the output is
turned ON.
2: When either of the work shortage warning or the overload warning
comes out, the output is turned ON.
3: Selection is not possible
4. Selection is not possible
5. Selection is not possible
6. In-operation signal interlocking to driving of parts feeder outputs on
terminal AL1-C1.
(Becomes the same behavior as terminal board
Y1A-Y1C)
When the output is ON, the space between the terminal AL1 and the
terminal C1 is short-circuited at the internal Tr.
To Next Page
