34
Display
Name Description
H03
Selection of IN2 input function
Selection of IN1 input function
Initial value: 0
(Refer to P.36 for display of input
state of IN1 and IN2)
In case H03 is 0 or1, terminal IN2 is effective when H00 is 4 or 7, or when H08 is 2.
In case H03 is 2 or 3, it is effective when H00 is 0~3.
In case H03 is 4, it is effective when H00 is 0~1.
0: When the terminal IN2 is at High level, the ON delay timer 2 works to turn the
terminal P2 ON. At 0V (Low level), the OFF delay timer 2 works to turn the
terminal P2 OFF. Otherwise, the work shortage timer works at 0V, and is reset
at High level.
1: When the terminal IN2 is 0V, the ON delay timer 2 works to turn the terminal P2
ON. (The signal of IN2 is reversed in logic and used for setting 0.)
2: When the terminal IN2 is 0V, the ON delay timer 2 works to turn the terminal P2
ON. At High level, the OFF delay timer 2 works to turn the terminal P2 OFF.
3: When the terminal IN1 is at High level, the ON delay timer 2 works to turn the
terminal P2 ON. (The signal of IN1 is reversed in logic and used for setting 2.)
4: With input signal of the terminal IN1, the ON delay timer works to turn the
terminal P2 ON. The terminal P2 turns OFF after the setting time of the OFF
delay timer 2.
When H03 is 2 or 3, in case the timer 2 is 0 second, signal of sensor 1
outputs to the terminal P2 directly.
When H03 is 4, the terminal P2 does not turn ON unless the OFF delay
timer 2 (H05) is set. Input logic of the terminal IN1 selects 0 or 1 at H00.
H04
ON delay timer 2
Initial value: 0.0 (second)
Set range:
0.0~60.0seconds
In case that the data of H03 is 0 or 1, the time between when the sensor 2(IN2)
start confirming the work and when the terminal P2 turns ON is set.
In case that the data of H03 is 2 or 3, the time between the sensor 1 (IN1) start
confirming the work and when the terminal P” turns ON is set.
In case that the data of H03 is 4, the time between when the sensor 1 (IN1) stops
confirming the work and when the terminal P2 turns ON is set.
Note) It is effective only when the data of selection (J02) of the driving method is 0,
1 or 3 (the use of the overflow detection sensor is selected).
H05
OFF delay timer 2
Initial value: 0.0 (second)
Set range:
0.0~30.0seconds
In case that the data of H03 is 0 or 1, the time between when the sensor 2 (IN2)
stops confirming the work and when the terminal P2 turns OFF is set.
In case that the data of H03 is 2 or 3, the time between when the sensor 1 (IN1)
stops confirming the work and when the terminal P2 turns OFF is set.
In case that the data of H03 is 4, the time between when the terminal P2 turns ON
and when the terminal P2 turns OFF is set.
Note) It is effective only when the data of selection (J02) of the driving method is 0,
1 or 3 (the use of the overflow detection sensor is selected).
H06
Soft start time
Initial value: 0.5 (second)
Set range:
0.0~5.0 seconds
Set the soft start time. The output voltage is gradually raised from 0V until it
reaches the set value. The time of the raising is set. The minimum set time is 0.0
second, but actually it is about 50msec.
H07
Soft stop time
Initial value: 0.3 (second)
Set range:
0.0~5.0seconds
Set the soft stop time. The output voltage is gradually lowered from the set value
until it reaches 0V. The time of the lowering is set. The minimum set time is 0.0
second, but actually it is about 50msec.
H08 Use of work shortage timer
Initial value: 0
Whether doing the work shortage detection is set. When doing it, the sensor used
is selected (IN1 or IN2).
0: Does not use
1: Uses the signal IN1(Work shortage is detected with overflow sensor.)
2: Uses the signal IN2(Work shortage is detected with different sensor from
overflow sensor.)
The signal selected by 1 or 2 is sent to the work shortage timer (H09) and the work
shortage reset timer (H10). When 4 to 7 is selected with H00, it is not possible to
use (it becomes H08=0).
To Next Page
