54
b.
mlnx-ofed-all Installs all available packages in MLNX_OFED
mlnx-ofed-basic Installs basic packages required for running
NVIDIAcards
mlnx-ofed-guest Installs packages required by guest OS
mlnx-ofed-hpc Installs packages required for HPC
mlnx-ofed-hypervisor Installs packages required by hypervisor OS
mlnx-ofed-vma Installs packages required by VMA
mlnx-ofed-vma-eth Installs packages required by VMA to work over
Ethernet
mlnx-ofed-vma-vpi Installs packages required by VMA to support VPI
bluefield Installs packages required for BlueField
dpdk Installs packages required for DPDK
dpdk-upstream-libs Installs packages required for DPDK using RDMA-Core
kernel-only Installs packages required for a non-default kernel
Note: MLNX_OFED provides kernel module RPM packages with KMP support for RHEL
and SLES. For other operating systems, kernel module RPM packages are provided only
for the operating system's default kernel. In this case, the group RPM packages have
the supported kernel version in their package's name.
Example:
mlnx-ofed-all-3.17.4-301.fc21.x86_64.noarch : MLNX_OFED all installer package for kernel 3.17.4-301.
fc21.x86_64 (without KMP support)
mlnx-ofed-basic-3.17.4-301.fc21.x86_64.noarch : MLNX_OFED basic installer package for kernel 3.17.4-3
01.fc21.x86_64 (without KMP support)
mlnx-ofed-guest-3.17.4-301.fc21.x86_64.noarch : MLNX_OFED guest installer package for kernel 3.17.4-3
01.fc21.x86_64 (without KMP support)
mlnx-ofed-hpc-3.17.4-301.fc21.x86_64.noarch : MLNX_OFED hpc installer package for kernel 3.17.4-301.
fc21.x86_64 (without KMP support)
mlnx-ofed-hypervisor-3.17.4-301.fc21.x86_64.noarch : MLNX_OFED hypervisor installer package for
kernel 3.17.4-301.fc21.x86_64 (without KMP support)
mlnx-ofed-vma-3.17.4-301.fc21.x86_64.noarch : MLNX_OFED vma installer package for kernel 3.17.4-301.
fc21.x86_64 (without KMP support)
mlnx-ofed-vma-eth-3.17.4-301.fc21.x86_64.noarch : MLNX_OFED vma-eth installer package for kernel
3.17.4-301.fc21.x86_64 (without KMP support)
mlnx-ofed-vma-vpi-3.17.4-301.fc21.x86_64.noarch : MLNX_OFED vma-vpi installer package for kernel
3.17.4-301.fc21.x86_64 (without KMP support)
mlnx-ofed-hypervisor-3.17.4-301.fc21.x86_64.noarch : MLNX_OFED hypervisor installer package for
kernel 3.17.4-301.fc21.x86_64 (without KMP support)
mlnx-ofed-vma-3.17.4-301.fc21.x86_64.noarch : MLNX_OFED vma installer package for kernel 3.17.4-301.
fc21.x86_64 (without KMP support)
mlnx-ofed-vma-eth-3.17.4-301.fc21.x86_64.noarch : MLNX_OFED vma-eth installer package for kernel
3.17.4-301.fc21.x86_64 (without KMP support)
mlnx-ofed-vma-vpi-3.17.4-301.fc21.x86_64.noarch : MLNX_OFED vma-vpi installer package for kernel
3.17.4-301.fc21.x86_64 (without KMP support)
When using an operating system different than RHEL or SLES, or you have installed a
kernel that is not supported by default in MLNX_OFED, you can use the
mlnx_add_kernel_support.sh script to build MLNX_OFED for your kernel.
The script will automatically build the matching group RPM packages for your kernel so
that you can still install MLNX_OFED via yum.
Please note that the resulting MLNX_OFED repository will contain unsigned RPMs,
therefore, you should set 'gpgcheck=0' in the repository configuration file.
Install the desired group.
# yum install mlnx-ofed-all
Loaded plugins: langpacks, product-id, subscription-manager
