Nvidia ConnectX-7 - Page 91

91
Pin# Signal Name Wire Type Detailed
Description
AWG# Pin# on the
other end
22 GND GND BAR 22
23 PCIE_CPU_CX_9N Micro coax Connect from the
Black Cabline CA-II
Plus cable through
220nF capacitors to
the x16 PCIe Tx
lanes of the CPU/
GPU/End-Point
38 23
24 PCIE_CPU_CX_9P Micro coax Connect from the
Black Cabline CA-II
Plus cable through
220nF capacitors to
the x16 PCIe Tx
lanes of the CPU/
GPU/End-Point
38 24
25 GND GND BAR 25
26 PCIE_CPU_CX_8N Micro coax Connect from the
Black Cabline CA-II
Plus cable through
220nF capacitors to
the x16 PCIe Tx
lanes of the CPU/
GPU/End-Point
38 26
27 PCIE_CPU_CX_8P Micro coax Connect from the
Black Cabline CA-II
Plus cable through
220nF capacitors to
the x16 PCIe Tx
lanes of the CPU/
GPU/End-Point
38 27
28 GND GND BAR 28
29 PCIE_CPU_CX_7N Micro coax Connect from the
Black Cabline CA-II
Plus cable through
220nF capacitors to
the x16 PCIe Tx
lanes of the CPU/
GPU/End-Point
38 29
30 PCIE_CPU_CX_7P Micro coax Connect from the
Black Cabline CA-II
Plus cable through
220nF capacitors to
the x16 PCIe Tx
lanes of the CPU/
GPU/End-Point
38 30
31 GND GND BAR 31
