Nvidia ConnectX-7 User Manual

92
Pin# Signal Name Wire Type Detailed
Description
AWG# Pin# on the
other end
32 PCIE_CPU_CX_6N Micro coax Connect from the
Black Cabline CA-II
Plus cable through
220nF capacitors to
the x16 PCIe Tx
lanes of the CPU/
GPU/End-Point
38 32
33 PCIE_CPU_CX_6P Micro coax Connect from the
Black Cabline CA-II
Plus cable through
220nF capacitors to
the x16 PCIe Tx
lanes of the CPU/
GPU/End-Point
38 33
34 GND GND BAR 34
35 PCIE_CPU_CX_5N Micro coax Connect from the
Black Cabline CA-II
Plus cable through
220nF capacitors to
the x16 PCIe Tx
lanes of the CPU/
GPU/End-Point
38 35
36 PCIE_CPU_CX_5P Micro coax Connect from the
Black Cabline CA-II
Plus cable through
220nF capacitors to
the x16 PCIe Tx
lanes of the CPU/
GPU/End-Point
38 36
37 GND GND BAR 37
38 PCIE_CPU_CX_4N Micro coax Connect from the
Black Cabline CA-II
Plus cable through
220nF capacitors to
the x16 PCIe Tx
lanes of the CPU/
GPU/End-Point
38 38
39 PCIE_CPU_CX_4P Micro coax Connect from the
Black Cabline CA-II
Plus cable through
220nF capacitors to
the x16 PCIe Tx
lanes of the CPU/
GPU/End-Point
38 39
40 GND GND BAR 40
41 PCIE_CPU_CX_3N Micro coax Connect from the
Black Cabline CA-II
Plus cable through
220nF capacitors to
the x16 PCIe Tx
lanes of the CPU/
GPU/End-Point
38 41

Nvidia ConnectX-7 Specifications

General

Supported Protocols	Ethernet, InfiniBand
RoHS Compliance	Yes
Ports	1 or 2 ports
Data Transfer Rate	Up to 400 Gb/s
Ethernet Speeds	10/25/40/50/100/200/400
InfiniBand Speeds	400Gb/s
Latency	Sub-600 nanoseconds
Form Factor	OCP 3.0
Product Type	Network Interface Card (NIC)
Power Consumption	Varies by model and configuration
