11.4 System PLL
[1] Data based on characterization results, not tested in production.
[2] PLL set-up requires high-speed start-up and transition to normal mode. Lock times are only valid when
high-speed start-up settings are applied followed by normal mode settings. The procedure for setting up the
PLL is described in the LPC5411x user manual.
[3] PLL current measured using lowest CCO frequency to obtain the desired output frequency.
Table 24. PLL lock times and current
T
amb
=  40  C to +105  C. V
DD
= 1.62 V to 3.6 V.
Symbol Parameter Conditions Min Typ Max Unit
PLL configuration: input frequency 12 MHz; output frequency 75 MHz
t
lock(PLL)
PLL lock time PLL set-up procedure followed
[2]
- - 400 s
I
DD(PLL)
PLL current when locked
[1][3]
- - 550 A
PLL configuration: input frequency 12 MHz; output frequency 100 MHz
t
lock(PLL)
PLL lock time PLL set-up procedure followed
[2]
- - 400 s
I
DD(PLL)
PLL current when locked
[1][3]
- - 750 A
PLL configuration: input frequency 32.768 kHz; output frequency 75 MHz
t
lock(PLL)
PLL lock time -
[1]
- - 6250 s
I
DD(PLL)
PLL current when locked
[1][3]
- - 450 A
PLL configuration: input frequency 32.768 kHz; output frequency 100 MHz
t
lock(PLL)
PLL lock time -
[1]
- - 6250 s
I
DD(PLL)
PLL current when locked
[1][3]
- - 560 A
