6.2 Pin description
On the LPC5411x, digital pins are grouped into two ports. Each digital pin may support up
to four different digital functions and one analog function, including General Purpose I/O
(GPIO).
Table 4. Pin description
Symbol
49-pin
64-pin
Reset state
[1]
Type
Description
PIO0_0 A6 31
[2]
PU I/O PIO0_0 — General-purpose digital input/output pin.
Remark: In ISP mode, this pin is set to the Flexcomm Interface 0 USART RXD
function.
I/O FC0_RXD_SDA_MOSI — Flexcomm Interface 0: USART RXD, I2C SDA, SPI
MOSI.
I/O FC3_CTS_SDA_SSEL0 — Flexcomm Interface 3: USART CTS, I2C SDA, SPI
SSEL0.
I CTimer0_CAP0 — 32-bit CTimer0 capture input 0.
R — Reserved.
O SCT0_OUT3 — SCT0 output 3. PWM output 3.
PIO0_1 B6 32
[2]
PU I/O PIO0_1 — General-purpose digital input/output pin.
Remark: In ISP mode, this pin is set to the Flexcomm Interface 0 USART TXD
function.
I/O FC0_TXD_SCL_MISO — Flexcomm Interface 0: USART TXD, I2C SCL, SPI MISO.
I/O FC3_RTS_SCL_SSEL1 — Flexcomm Interface 3: USART RTS, I2C SCL, SPI
SSEL1.
I CTimer0_CAP1 — 32-bit CTimer0 capture input 1.
R — Reserved.
O SCT0_OUT1 — SCT0 output 1. PWM output 1.
PIO0_2 - 36
[2]
PU I/O PIO0_2 — General-purpose digital input/output pin.
I/O FC0_CTS_SDA_SSEL0
— Flexcomm Interface 0: USART CTS, I2C SDA, SPI
SSEL0.
I/O FC3_SSEL3 — Flexcomm Interface 3: SPI SSEL3.
I CTimer2_CAP1 — 32-bit CTimer2 capture input 1.
PIO0_3 - 37
[2]
PU I/O PIO0_3 — General-purpose digital input/output pin.
I/O FC0_RTS_SCL_SSEL1
— Flexcomm Interface 0: USART RTS, I2C SCL, SPI
SSEL1.
I/O FC2_SSEL2 — Flexcomm Interface 2: SPI SSEL2.
O CTimer1_MAT3 — 32-bit CTimer1 match output 3.
PIO0_4 C7 38
[2]
PU I/O PIO0_4 — General-purpose digital input/output pin.
Remark: The state of this pin at Reset in conjunction with PIO0_31 and PIO1_6 will
determine the boot source for the part or if ISP handler is invoked. See the Boot
Process chapter in UM10914 for more details.
I/O FC0_SCK — Flexcomm Interface 0: USART or SPI clock.
I/O FC3_SSEL2 — Flexcomm Interface 3: SPI SSEL2.
I CTimer0_CAP2 — 32-bit CTimer0 capture input 2.
