32-bit ARM Cortex-M4/M0+ microcontroller
[1] Characterized but not implemented as production test. Guaranteed by design.
Fig 26. Differential data-to-EOP transition skew and EOP width
002aab561
T
PERIOD
differential
data lines
crossover point
source EOP width: t
FEOPT
receiver EOP width: t
EOPR1
, t
EOPR2
crossover point
extended
differential data to
SE0/EOP skew
n × T
PERIOD
+ t
FDEOP
