(4) Conform the label color of the image drum cartridge to the label color of the printer.
(5) Return the 4 image drum cartridges gently.
Labels
Label
(6) Turn the 4 blue levers of the toner cartridges fully in the direction of arrow.
Note!
• The starter toner (the toner cartridge attached to the product at the time of purchase)
can print approximately 1,000 sheets of A4 paper in case of 5% coverage.
(Approximately 500 sheets in case of OEL/AOS specification)
• Confirm whether the lever of the toner cartridge is turned fully in the direction of arrow
when the LED lighting of no toner on the operation panel is on indefinitely.
Lighting of LED
Blue Lever
