43163501TH Rev.1 86 /
8 43217001 Fuser-Assy. (n)
43396001 Fuser-Assy. (Ln)
9-1 43206501 Guide-Assy.-Eject-U
Apply MOLYKOTE (HP-300) to the hatched areas.
HP-300 Class C
Cam-Release
Lever-Release
Not allowed to stain
the area with grease
Apply MOLYKOTE (EM-30L) to the sliding portions (hatching portions).
EM-30L Class S
The application of grease protruding over
on the paper carriage surface is not permitted.
To Next Page
