43163501TH Rev.1 88 /
0-1 43192001 Printer-Unit-PX732
Apply MOLYKOTE (EM-30L) to the terminal tip areas.
EM-30L Class C
Apply MOLYKOTE (EM-30L) to the hatched areas
.
EM-30L Class C
Apply MOLYKOTE (EM-30L) to the hatched areas.
EM-30L Class C
Apply MOLYKOTE (EM-30L) to the end face.
EM-30L Class C
Apply areas to grease (
4
Plate-Shield-Rear (Caulking)
Gear-Idle-Belt
