- 177 -
Windows utilities
4
5
1
2
3
Convenient print
functions
Appendix Index
Checking and
Changing Printer
Settings Using
the Control Panel
Network
Setup
Matching
Colors
Using Utility
Software
Registering ICC proles
You can register and edit printer proles. Some
of the functions are explained below.
To register an ICC prole, it is necessary to
mount the (optional) HDD to the device.
Note
z
If using the prole registration and edit functions, install
the Storage Manager plug-in.
Reference
z
For how to install plug-ins, see “Installing” (P.172).
1
Select [Storage Manager] from the
[Plug-ins] menu.
2
Click [ ] to create a new project.
3
Click [ ], and change [File type] in the
[Open le] dialog box to "ICC prole
(*.ICC, *.ICM)".
4
Select the prole to be registered, and
click [Open].
5
Click [Component] in the ICC prole
added to the project to display the [Edit
le] dialog box.
6
Select the number of the prole to be
registered.
The numbers already used in the project
cannot be selected, and are displayed
against a yellow background.
7
If necessary, enter a comment in the
[Comments] eld.
8
Click the [OK] button to apply the changes.
9
Select the printer from the device list at
the bottom of the window.
10
Click [ ] to send the project associated to
the ICC prole that has been added to the
printer.
11
Check that the message "Finished." is
displayed, and click [OK].
Registering forms (form overlay)
You can register the logos, etc., as forms to the
device, and overlay for printing. This section
explains how to register forms.
Reference
z
For how to print overlays, see “Printing using registered
forms (overlay printing)” (P.95).
Memo
z
If using Windows PS printer drivers, administrator
privileges are required.
Creating forms
1
Click [Start], and then select [Devices
and printers].
2
Right-click the [OKI (product name)
(**)] icon (** describes the printer
driver type: PS, PCL6, or XPS), and
select [Printer properties].
3
Select the [Port] tab, and enable the
[FILE:] check box in [Printer port], and
click [OK].
4
Create the form to be registered to the
printer.
If using Windows PCL printer drivers, go to
Step 9.
5
Select [Print] from the [File] menu.
6
Click [Advanced] (or [Preferences]).
7
Select the [Job Options] tab, and click
[Overlay].
8
Select [Create form].
9
Printing will be implemented.
10
Enter the name of the le to be saved.
11
Restore the [Printer port] in the [Port]
tab.
To Next Page
