4.3.1 Cover-Rear, Cover-Side (R), and Cover-Side (R) Rear
(1) Open Cover Assy-Top
.
(2) Unscrew the 5 screws
, then remove Cover-Rear .
(3) Unscrew the 2 screws
, then remove Cover-Side (R) with it warped.
(4) Unscrew the screws
, then remove Cover-Side (R) Rear .
