2.4.2 Paper Processing Mechanism
Figure 2-4 illustrates how the paper transfers through the C9850.
Face down stacker
Fuser assembly
Head × 4
Unit × 4
Discharge roller
Heat roller
Regist roller
Assy (B)
Hopping roller
Belt unit
Reverse Roller
High-pressure
Multipurpose tray
power supply
Intermediate Feed
Backup roller
Cassette 1
Roller Assy
Cassette 2
Discharge roller × 4
Cassette 3
Regist roller Assy (A)
Cassette 4
Cassette 5
Regist roller Assy (A)
Retard Roller
Figure 2-4 Paper Path
