4.3.17 Low Voltage Power Source Assy and Motor-FAN
(1) Remove the Power Unit. (Refer to Section 4.3.16)
(2) Unscrew the 3 screws
, then remove the low Voltage Power Source Assy , and
Film-Insulation .
(3) Unscrew the 2 screws
, then remove the connector and Motor-FAN .
