Oki C9850

Oki Data CONFIDENTIAL
43627911TH Rev. 3
126 /
Lever
× 14
4.3.16 Power Unit
(1) Remove the Cover-Rear. (Refer to Section 4.3.1)
(2) Unscrew the 12 screws
, disconnect all connectors, pull out the lever then remove
the Power Unit .
Do not push the cable upward,
or allow slack in it above the
partition.
When installing a power supply
unit, lay the cable at the top of
the power unit in the shape as
shown.
