4.3.3 Stacker Assy-FU
(1) Open Cover Assy-Top
.
(2) Open Stacker Assy-FU
, then remove the 2 stoppers . Push these to one side,
remove the post, then remove the Stacker Assy-FU .
(3) Open the Stacker Assy-FU
. Move the two stoppers sideways and take them
off. Remove the Stacker Assy-FU .
