4.3.2 Cover-Side (L) and Cover Assy-Front
(1) Open Cover Assy-Top
.
(2) Unscrew the 4 screws
, then remove the Cover-Side (L) .
(3) Open the Cover Assy-Front
by 90°, unscrew the 2 screws , then slide the Assy
to the side and remove.
