Oki Data CONFIDENTIAL
43627911TH Rev. 3
190 /
7.5.2 Preparing for Troubleshooting
(1) Operation Panel Display
The state of malfunction is displayed on the LCD (Liquid Crystal Display) of the op-
erator panel of this machine.
Execute proper repairs according to the message indicated on the LCD.
Note! W
hen replacing the engine PCB (S2V PWB), remove the EEPROM chip from the old
PC
B and then put the EEPROM that was removed on the new PCB replacement.
Order
Malfunction Details Flowchart No.
1 The machine does not operate properly after turning
ON the power.
2 Jam Error
Paper Supply Jam (1st Tray)
Paper Supply Jam (Multipurpose Tray)
Fee Jam
Paper Output Jam
Double-Side Print Jam
-1
-2
-3
-4
-5
3 Paper Size Error
4 I/D UP/DOWN Error
5 Fuser Unit Error
6 Fan Motor Error
To Next Page
