Table 5-2 Motor and Clutch Test
Unit Name Display Drive Limitation
Error display
Remarks
K-ID MOTOR - - -
Y-ID MOTOR - - -
M-ID MOTOR - - -
C-ID MOTOR - - -
BELT MOTOR - - -
FUSER MOTOR - - -
FUSER MOTOR REVERSE - - -
FUSER RLS - - -
REGIST MOTOR - - -
REGIST CLUTCH - - -
MPT MOTOR - - -
MPT LIFT UP - - -
EXIT SOLENOID - - -
FACEDOWN SOLENOID - - -
REGISTRATION SHUTTER - - -
JOB OFFSET - - -
TRAY1 MOTOR - - -
TRAY2 MOTOR TRAY 2 is installed. - OPTION
TRAY3 MOTOR TRAY 3 is installed. - OPTION
TRAY4 MOTOR TRAY 4 is installed. - OPTION
TRAY5 MOTOR TRAY 5 is installed. - OPTION
TRAY2 FEED MOTOR TRAY 2 is installed and the cassette is not installed. - OPTION
TRAY3 FEED MOTOR TRAY 2 is installed and the cassette is not installed. - OPTION
TRAY4 FEED MOTOR TRAY 2 is installed and the cassette is not installed. - OPTION
TRAY5 FEED MOTOR TRAY 2 is installed and the cassette is not installed. - OPTION
TRAY2 ROLLER CLUTCH TRAY 2 is installed. - OPTION
TRAY3 ROLLER CLUTCH TRAY 3 is installed. - OPTION
TRAY4 ROLLER CLUTCH TRAY 4 is installed. - OPTION
TRAY5 ROLLER CLUTCH TRAY 5 is installed. - OPTION
TRAY1 GEARED MOTOR - - -
TRAY2 GEARED MOTOR TRAY 2 is installed. - OPTION
TRAY3 GEARED MOTOR TRAY 3 is installed. - OPTION
TRAY4 GEARED MOTOR TRAY 4 is installed. - OPTION
TRAY5 GEARED MOTOR TRAY 5 is installed. - OPTION
DUP MOTOR Duplex unit is installed. - OPTION
DUP FAN Duplex unit is installed. - OPTION
