Oki C9850 - Page 224

Oki Data CONFIDENTIAL
43627911TH Rev. 3
224 /
Unit Circuit Diagram and Configuration Parts Diagram Resistance Value
Geared Motor
Waste Toner
Transfer Motor
Main Cooling Fan
(PULL)
and Cooling Fan
for Controller
IC1
IP2
-
CN-1
+
M
CN-2
Red
Black
+24V
1
FANALM-N
3
0V
2
M
White
