3. Maintenance
2
Press the open button (A) and open the output tray (a).
3
Tilt forward the fuser unit lock levers (b) to unlock.
4
Hold the fuser unit handle (c) and lift the fuser unit out of the machine.
5
Push the blue lever on the new fuser unit and remove the orange safety
stopper.
Possible to get burned.
Since the fuser unit gets hot, carry out the operation carefully, and when lifting it up you
must hold it by the handle. Do not try to hold it whilst it is hot. Wait until it has cooled
down and then carry out the operation.
