Oki MC873dn User Manual

Oki Data CONFIDENTIAL
2. TROUBLESHOOTING PROCEDURES
45850101TH Rev.1
2-83
2.6 Fuse Checking
If any of the following errors occurs, check the corresponding fuse on the CU/PU control
board or or Scanner board aor high voltage power supply board. (Refer to following Table)
Fuse Name Error Description Insert Point Resistance
CU/PU board
(6CU)
F1 Paper jam in an option
tray during printing.
Option trays (Tray2 to Tray4): 24V 1Ω or less
F2 Service call 918 Duplex unit: 24V
F3 Service call 122 High-voltage power supply unit,
low-voltage FAN, belt FAN,
shutter solenoid, belt fuse,
ID fuse, discharging light,
fuser FAN: 24V
F4 Not displayed on the
operator panel.
CU part: 3.3V
F5 Not displayed on the
operator panel.
CU/PU part: 5V
F6 Paper jam in Tray 1
during printing.
Service call 140
Hopping clutch, registration clutch,
MPT clutch, ID UP clutch,
hopping motor: 24V
F8 Service call 928 Belt motor, ID motor FAN,
fuser side FAN:24V
F9 CM color missing CM heads: 5V
F10 Service call 134 KYMC heads: 3.3V
F11 KY color missing KY heads: 5V
F12 WLAN error HOSTUSB: 5V
F13 Stapler error
Service call 090
Stapler:24V
F14 Doesn't start-up.
The hourglass-mark
is displayed on the
operator panel.
SATA:5V
F15 Not connected LAN.
Not lighted Power
LED.
CU/PU part: 5V
Fuse Name Error Description Insert Point Resistance
Scanner board
(6SU)
F1 JAM <0103> ADF Transfer Motor 1Ω or less
F2 Doesn't start-up.
The hourglass-mark
is displayed on the
operator panel.
CIS,USB-VBUS,Speaker,FAX
F3 JAM <0101> ADF Feed Motor
F4 Doesn't start-up.
The hourglass-mark
is displayed on the
operator panel.
SU part:3.3V
F5 Carriage Error <02> ADF Clutch, FB Motor, FAX,
Multi feed Sensor
F6 Not displayed on the
operator panel.
SU part:3.3V,Operator Panel:3.3V
F7 Not displayed on the
operator panel.
Paper size detect sensor,Operator
Panel:5V
Fuse Name Error Description Insert Point Resistance
High-Voltage
Power board
(EHV)
F501 Cover open High-voltage power supply: 24V 1Ω or less

Oki MC873dn Specifications

General

Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	9.5 s
Print speed (black, normal quality, A3)	20 ppm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 1200 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	10 s
Copy speed (black, normal quality, A4)	35 cpm
Scan to	CIFS, E-mail, FTP, HTTP, Image, USB
Scan drivers	TWAIN
Scanner type	ADF scanner
Output color depth	24 bit
Scan speed (color)	50 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 600 DPI
Faxing	Color faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	1000
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	75000 pages per month
Page description languages	Epson FX, IBM ProPrinter, PCL 5c, PCL 6, PDF 1.7, PostScript 3
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, EAP, SSL/TLS, WPA2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP, DHCP, DHCPv6, BOOTP, HTTP, HTTPS, DNS, DDNS, WINS, , UPNP, Bonjour, SNMPv1&v3, SNTP, IPP, IPPS, WSD Print, WSD Scan, LLTD, IEEE802.1X, LPR, Port9100, Telnet, FTP, IPSEC, SecureProtocolServer, LDAP, LDAPS, CIFS, FTP, FTPS, SMTP, SMTPS, POP3
Internal memory	1260 MB
Internal storage capacity	250 GB
Sound power level (standby)	37 dB
Sound pressure level (printing)	54 dB
Paper input type	Paper tray
Total input capacity	300 sheets
Maximum input capacity	400 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	100 sheets
Envelopes sizes	10, C4, C5, DL, Monarch
Custom media width	148.5 - 297 mm
Custom media length	210 - 431.8 mm
Paper tray media types	Banner, Envelopes, Plain paper
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	64 - 256 g/m²
Auto Document Feeder (ADF) media weight	60 - 120 g/m²
Display	LCD
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Standard interfaces	Ethernet, RJ-11, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	2
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1400 W
Power consumption (off)	0.1 W
Power consumption (sleep)	3 W
Power consumption (PowerSave)	30 W
Power consumption (average operating)	850 W
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	600 mm
Width	563 mm
Height	700 mm
