45850101TH Rev.1
3-26
• The displays are switched to the following by pressing the [2] button.
BELT=xxx(***)
BELT: xxx = Belt temperature [Unit: ˚C]
*** = Belt thermistor scanning AD value [Unit: HEX]
5. Repeat steps 2 and 4 when necessary.
6. Press the [#] button to end the test (the state if step 1 is restored).
3.4.6 Color registration adjustment test
The color registration adjustment test is used for adjusting color registration or investigating
the cause(s) of color misregistration. Chapter 2 about description on color registration
adjustment should be followed for recovery from an error caused by the test.
1. Enter the self-diagnostic-mode(Level1) and, until the following message
appears, press the [2] or [8] button.
REG ADJUST TEST
2. Press the [6] button. The following message appears. Press the [2] or [8] button
until the intended option appears.
REG ADJUST TEST
REG ADJ EXECUTE
3. Press the [6] button. The displayed option is performed:
When the displayed option is REG ADJ EXECUTE:
①
Color registration adjustment test (the ONLINE lamp starts blinking) is
performed.
②
When the test ends, the upper display shows the result of the test (OK or an
error name), the lower display shows ‘****RESULT’.
OK
REG ADJ RESULT
Pressing the [2] button displays the next test result.
Pressing the [8] button displays the preceding test result.
Press the [4] button to return to step 2.
Remark: The following message appears while the printer is initialized or issues
an alarm or when the cover is open.
NG
REG ADJ RESULT
③
Pressing the [#] button during the test cancels the test (turning on the ONLINE
lamp), restoring the state of step 2.
To Next Page
