2. TROUBLESHOOTING PROCEDURES
45850101TH Rev.1
2-84
2.7 Paper cassette switches and paper size correlation table
(1) Source tray
Switch Part No. 2052000P4000
Model No: HS12-001
Bit Number Dial Indication Size
1 2 3 4 TRAY1 TRAY2/TRAY3/TRAY4
H H H H No cassette No cassette
H L H L A6 A4 LEF
L H L L Other Other
H L L H Tabloid Tabloid
L L H H Legal Legal
L H H L Letter Letter
H H L H Letter LEF Letter LEF
H L H H Executive Executive
L H H H B4 B4
H H H L B5 B5
H H L L B5 LEF B5 LEF
H L L L A3 A3
L L L L A4 A4
L L L H A4 LEF A4 LEF
L L H L A5 A5
L H L H A5 LEF A3
Press of SW: L
• When “Legal” is selected, three options, “Legal 13”, “Legal 13.5” and “Legal 14”
are selectable.
