3. MAINTENANCE MENUS
3.4.2 Normal self-diagnostic mode (Level 1)
The normal self-diagnostic mode menus are as follows:
Option Self-diagnosis Menu Adjustment
1 Switch scan test SWITCH SCAN Checks input sensor and
switch
2 Motor clutch test MOTOR&CLTCH
TEST
Tests the operation of a motor
or clutch.
3 Test printing TEST PRINT Prints a test pattern stored in
the PU.
4 Color registration
adjustment test
REG ADJUST TEST Judges the color registration
adjustment mechanism as
pass or fail.
5 Density
adjustment test
DENS ADJ TEST Judges the density adjustment
mechanism as pass or fail.
6 Consumable
counter display
CONSUMABLE
STATUS
Displays the usage of a
consumable.
7 Consumable life
counter display
PRINTER STATUS Displays the life counter of a
consumable.
8 Factory/Shipping
mode switching
FACTORY MODE
SET
Switches between Factory and
Shipping modes
9 Fuse status
display
Displays the status of a fuse.
10 Engine parameter
setting
SENSOR SETTING Sets whether to enable
or disable error detection
performed by each sensor.
11 Display of LED
head serial
number
LED HEAD DATA Displays the serial number of
LED head data.
12 NVRAM
parameter setting
NVRAM
PARAMETER
Must not be used.
13 Drum Manual
Cleaning
DRUM CLEANING Cleans a drum manually.
3.4.2.1 Entering self-diagnostic mode (level 1)
Note! Entering the System Maintenance mode of MC853/MC873/ES8453/ES8473
requires a password. Refer to 3.1 Maintenance Menu for description on it.
1.Select the "Device Settings" by touch panel.
2.Enter [#]
→
[0]
→
[1]
→
[0]
→
[3]
→
[*] at "Device Settings" display.
3.Enter the password "000000" and touch [OK] button.
4.Select the "Print Maintenance"
→
"Engine Diag Mode"
3.4.2.2 Exiting self-diagnostic mode
1. Turn of the printer and, after ten seconds, turn it on.

Oki MC873dn Specifications

General

Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	9.5 s
Print speed (black, normal quality, A3)	20 ppm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 1200 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	10 s
Copy speed (black, normal quality, A4)	35 cpm
Scan to	CIFS, E-mail, FTP, HTTP, Image, USB
Scan drivers	TWAIN
Scanner type	ADF scanner
Output color depth	24 bit
Scan speed (color)	50 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 600 DPI
Faxing	Color faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	1000
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	75000 pages per month
Page description languages	Epson FX, IBM ProPrinter, PCL 5c, PCL 6, PDF 1.7, PostScript 3
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, EAP, SSL/TLS, WPA2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP, DHCP, DHCPv6, BOOTP, HTTP, HTTPS, DNS, DDNS, WINS, , UPNP, Bonjour, SNMPv1&v3, SNTP, IPP, IPPS, WSD Print, WSD Scan, LLTD, IEEE802.1X, LPR, Port9100, Telnet, FTP, IPSEC, SecureProtocolServer, LDAP, LDAPS, CIFS, FTP, FTPS, SMTP, SMTPS, POP3
Internal memory	1260 MB
Internal storage capacity	250 GB
Sound power level (standby)	37 dB
Sound pressure level (printing)	54 dB
Paper input type	Paper tray
Total input capacity	300 sheets
Maximum input capacity	400 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	100 sheets
Envelopes sizes	10, C4, C5, DL, Monarch
Custom media width	148.5 - 297 mm
Custom media length	210 - 431.8 mm
Paper tray media types	Banner, Envelopes, Plain paper
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	64 - 256 g/m²
Auto Document Feeder (ADF) media weight	60 - 120 g/m²
Display	LCD
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Standard interfaces	Ethernet, RJ-11, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	2
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1400 W
Power consumption (off)	0.1 W
Power consumption (sleep)	3 W
Power consumption (PowerSave)	30 W
Power consumption (average operating)	850 W
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	600 mm
Width	563 mm
Height	700 mm
