Oki MC873dn User Manual

Oki Data CONFIDENTIAL
45850101TH Rev.1
2-64
2. TROUBLESHOOTING PROCEDURES
2.5.5. (3-6) Paper size error (Error code: 400 and 401)
(3-6-1) Printing was stopped when paper ejected after paper size error detected.
Check item Check work
Actions to be taken
at NG
(3-6-1-1) Check paper feed condition
Multi-feed of papers Check whether multi-feed paper ejected or not. If multi-feed
occurs again
after the open
and close the
front cover,
replace the
retard roller of
the tray in use.
Paper size Does the paper size specified for print match the
paper size of paper stuck in the tray.
Change the
specified paper
size or size of
paper inside the
tray.
IN1 sensor, IN2
sensor
Check if shape and movement of the sensor
levers have any abnormality or not.
Replace the
sensor lever with
the good sensor
lever.
2.5.5.(4) ID unit Up/Down error (Service call 142)
(4-1) Error occurs during the Up movement of the ID unit
Check item Check work
Actions to be taken
at NG
(4-1-1) Check the mechanical load during the Up movement
Mechanical load
during installation
and removal of the
ID unit
Check if abnormal heavy load is applied when
removing the ID unit.
IReplace the ID
unit, or replace
the right/left side
plate.
If any attempt
of using new ID
unit as a trial
is going to be
made, be sure to
use the System
Maintenance
Menu FUSE
KEEP MODE.
Greasing to the right
and left Up/Down
link levers
Check if the slant surface of the link lever is
coated by grease or not.
Apply grease.
Assembled condition
of the right and left
Up/Down link levers
Check if any part exists or not in the vicinity of
link lever, that hampers movement of the link
lever.
Assemble them
correctly.
(4-1-2) Up/Down mechanism
Assembled condition
of the peripheral
mechanism of the
link lever
Is the mechanism assembled so that the link
lever is connected to the planetary driving gear?
Assemble them
correctly.
Right and left link
levers
Check if the link lever is set in the correct
position that enables the specified engagement
of gears.
(Check if the link lever is set in the wrong
position that results in the wrong engagement of
gears by several teeth.)
Assemble them
correctly.

Oki MC873dn Specifications

General

Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	9.5 s
Print speed (black, normal quality, A3)	20 ppm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 1200 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	10 s
Copy speed (black, normal quality, A4)	35 cpm
Scan to	CIFS, E-mail, FTP, HTTP, Image, USB
Scan drivers	TWAIN
Scanner type	ADF scanner
Output color depth	24 bit
Scan speed (color)	50 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 600 DPI
Faxing	Color faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	1000
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	75000 pages per month
Page description languages	Epson FX, IBM ProPrinter, PCL 5c, PCL 6, PDF 1.7, PostScript 3
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, EAP, SSL/TLS, WPA2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP, DHCP, DHCPv6, BOOTP, HTTP, HTTPS, DNS, DDNS, WINS, , UPNP, Bonjour, SNMPv1&v3, SNTP, IPP, IPPS, WSD Print, WSD Scan, LLTD, IEEE802.1X, LPR, Port9100, Telnet, FTP, IPSEC, SecureProtocolServer, LDAP, LDAPS, CIFS, FTP, FTPS, SMTP, SMTPS, POP3
Internal memory	1260 MB
Internal storage capacity	250 GB
Sound power level (standby)	37 dB
Sound pressure level (printing)	54 dB
Paper input type	Paper tray
Total input capacity	300 sheets
Maximum input capacity	400 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	100 sheets
Envelopes sizes	10, C4, C5, DL, Monarch
Custom media width	148.5 - 297 mm
Custom media length	210 - 431.8 mm
Paper tray media types	Banner, Envelopes, Plain paper
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	64 - 256 g/m²
Auto Document Feeder (ADF) media weight	60 - 120 g/m²
Display	LCD
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Standard interfaces	Ethernet, RJ-11, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	2
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1400 W
Power consumption (off)	0.1 W
Power consumption (sleep)	3 W
Power consumption (PowerSave)	30 W
Power consumption (average operating)	850 W
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	600 mm
Width	563 mm
Height	700 mm
