3. MAINTENANCE MENUS
3.3 Maintenance Utility
The adjustments described in table 3-1 should be made by using Maintenance Utility. Details
on the utility are as follows:
(1) Maintenance Utility operation manuals:
42678821FU01 Rev.2 (Version 1.1.0) or higher (Japanese)
42678821FU02 Rev.2 (Version 1.1.0) or higher (English)
(2) Maintenance Utility program:
Applicable operating
system
File name Part number
Win XP/Vista/7/8 42678821FW01.zip 42678821FW01 Rev.2
(Version 2.1.0) or higher
Table 3-1 Maintenance Utility Adjustment Items
Item Adjustment
Section in
Maintenance
Utility
Operation
manual
Operation from
operator panel
(section in this
maintenance manual)
1 Board
Replace-
ment
Copies the information from the
EEPROM on the PU board, and copies
the EEPROM setting value on CU
board.
Purpose: To copy the information
stored on the EEPROM on the PU or
CU board when the CU/ or PU board
needs to be replaced with another one
due to maintenance.
3.1.1 Unavailable
2 Serial
number
setting
Rewrites the serial number recorded
on the PU, and Selects the printer
serial number recorded on the CU,
output mode, and rewrites the device
serial number.
Purpose: To configure a maintenance
replacement board to which the
information on the PU board cannot be
copied (due to an interface error).
3.2.1 Unavailable
Item Adjustment
Section in
Maintenance
Utility
Operation
manual
Operation from
operator panel
(section in this
maintenance manual)
3 Factory/
Shipping
Mode
Switches between Factory and
Shipping modes.
Purpose: To configure a maintenance
replacement PU board to which the
information on the EEPROM on the
PU board cannot be copied (due to an
interface error). The maintenance board
is set to the Factory mode usually by
default and, by using this function, must
be set to the Shipping mode.
3.2.3 Section 3.4.10
4 Mac
address
setting
Sets the Mac address 3.2.2 Unavailable
5 Network log
storage
Stores Network log files. 3.3.1 Unavailable
6 Send File Transmits a specified file. 3.1.2 Unavailable
7 PU log
storage
Stores PU log flies. 3.3.2 Unavailable
8 Test print Executes the local print function and
sends a specified file.
Purpose: To check the printer on
a stand-alone basis and send a
download file.
3.4 Perform local printing
(refer to System
Specification
9 Local Print
Data storage
Stores files of local print data 3.3.4 Unavailable
10 PU
maintenance
log storage
Stores self-diagnosis log files of printer
paper running system.
3.3.3
Unavailable
11 Migrate
Settings
Copy to another device by selecting
any values of various settings.
3.1.3 Unavailable
12 FUSE KEEP
mode setting
Sets the FUSE KEEP mode. 3.2.7 Unavailable

Oki MC873dn Specifications

General

Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	9.5 s
Print speed (black, normal quality, A3)	20 ppm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 1200 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	10 s
Copy speed (black, normal quality, A4)	35 cpm
Scan to	CIFS, E-mail, FTP, HTTP, Image, USB
Scan drivers	TWAIN
Scanner type	ADF scanner
Output color depth	24 bit
Scan speed (color)	50 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 600 DPI
Faxing	Color faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	1000
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	75000 pages per month
Page description languages	Epson FX, IBM ProPrinter, PCL 5c, PCL 6, PDF 1.7, PostScript 3
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, EAP, SSL/TLS, WPA2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP, DHCP, DHCPv6, BOOTP, HTTP, HTTPS, DNS, DDNS, WINS, , UPNP, Bonjour, SNMPv1&v3, SNTP, IPP, IPPS, WSD Print, WSD Scan, LLTD, IEEE802.1X, LPR, Port9100, Telnet, FTP, IPSEC, SecureProtocolServer, LDAP, LDAPS, CIFS, FTP, FTPS, SMTP, SMTPS, POP3
Internal memory	1260 MB
Internal storage capacity	250 GB
Sound power level (standby)	37 dB
Sound pressure level (printing)	54 dB
Paper input type	Paper tray
Total input capacity	300 sheets
Maximum input capacity	400 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	100 sheets
Envelopes sizes	10, C4, C5, DL, Monarch
Custom media width	148.5 - 297 mm
Custom media length	210 - 431.8 mm
Paper tray media types	Banner, Envelopes, Plain paper
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	64 - 256 g/m²
Auto Document Feeder (ADF) media weight	60 - 120 g/m²
Display	LCD
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Standard interfaces	Ethernet, RJ-11, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	2
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1400 W
Power consumption (off)	0.1 W
Power consumption (sleep)	3 W
Power consumption (PowerSave)	30 W
Power consumption (average operating)	850 W
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	600 mm
Width	563 mm
Height	700 mm
