2. TROUBLESHOOTING PROCEDURES
45850101TH Rev.1
2-3
2.5 Troubleshooting method
If a trouble occurs in the printer, search for it by the following procedure:
Problem
generated
Problem is displayed
in LCD.
Repair using the
"LCD message list"
(see 2.5.1 to 2.5.4).
Repair in detail using
troubleshooting flow
(see 2.5.5).
Abnormal image (or
problems that are
not displayed in the
LCD)
Repair in detail using
troubleshooting flow
(see 2.5.6).
2.5.1 Panel messages list
Initializing & Information
No. Category PJL Status
Code
Panel messages Description
1 Initializing - Menu Resetting Indicates that EEPROM of the controller side is
being reset.
The condition that EEPROM is reset includes the
followings.
- Changes of CU ROM (when disagreement of
CU F/W version is detected)
- Changes of destination channel
- Compulsive initialization of EEPROM ("Service
Menu"-"System Maintenance"-"ALL RESET")
- OEM set of PJL command
- Reset by a FactoryDefaults operator of PS
2 Initializing - Wait a moment.
Network initializing
...
The network is in initializing.
If this status occurred during the unit initialinzing
the message is displayed by English.
3 Initializing - Flash Memory
Format
Displays that Flash memory is being formatted.
It is displayed it when Resident/Option Flash
memory not fomented are detected, or "Service
Menu"-"System Maintenance"-"Format Flash
Memory" of a system maintenance menu is
performed.
The function mentioned above is secret to users.
Therefore, this status does not occur in a user
environment.
4 Initializing - Checking File
System
Displays that HDD file system is being checked.
Process Check of File System is valid to start
from "Management"-"Storage Maintenance
Setup" of Admin Setup Menu, or "Check File
System" of Boot Menu.
5 Initializing - Erasing Disk
%PERCENT%%
Indicates that the hard disk is being erased.
Erase process of the hard disk is valid to start
from "Management"-"Storage Maintenance
Setup"-"Erase SD Memory Card " of Admin Setup
Menu.

Oki MC873dn Specifications

General

Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	9.5 s
Print speed (black, normal quality, A3)	20 ppm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 1200 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	10 s
Copy speed (black, normal quality, A4)	35 cpm
Scan to	CIFS, E-mail, FTP, HTTP, Image, USB
Scan drivers	TWAIN
Scanner type	ADF scanner
Output color depth	24 bit
Scan speed (color)	50 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 600 DPI
Faxing	Color faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	1000
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	75000 pages per month
Page description languages	Epson FX, IBM ProPrinter, PCL 5c, PCL 6, PDF 1.7, PostScript 3
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, EAP, SSL/TLS, WPA2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP, DHCP, DHCPv6, BOOTP, HTTP, HTTPS, DNS, DDNS, WINS, , UPNP, Bonjour, SNMPv1&v3, SNTP, IPP, IPPS, WSD Print, WSD Scan, LLTD, IEEE802.1X, LPR, Port9100, Telnet, FTP, IPSEC, SecureProtocolServer, LDAP, LDAPS, CIFS, FTP, FTPS, SMTP, SMTPS, POP3
Internal memory	1260 MB
Internal storage capacity	250 GB
Sound power level (standby)	37 dB
Sound pressure level (printing)	54 dB
Paper input type	Paper tray
Total input capacity	300 sheets
Maximum input capacity	400 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	100 sheets
Envelopes sizes	10, C4, C5, DL, Monarch
Custom media width	148.5 - 297 mm
Custom media length	210 - 431.8 mm
Paper tray media types	Banner, Envelopes, Plain paper
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	64 - 256 g/m²
Auto Document Feeder (ADF) media weight	60 - 120 g/m²
Display	LCD
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Standard interfaces	Ethernet, RJ-11, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	2
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1400 W
Power consumption (off)	0.1 W
Power consumption (sleep)	3 W
Power consumption (PowerSave)	30 W
Power consumption (average operating)	850 W
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	600 mm
Width	563 mm
Height	700 mm
