3. MAINTENANCE MENUS
Table 3-3 SWITCH SCAN Detail
Lower display shows asterisk (*) when function on upper display is unavailable.
Upper display
1 2 3 4
Detail Lower display Detail Lower display Detail Lower display Detail Lower display
PAPER ROUTE : PU Entrance 1 Sensor
H: No paper exists.
L: Paper exists.
Entrance 2 Sensor
H: No paper exists.
L: Paper exists.
Write Sensor
H: No paper exists.
L: Paper exists.
Exit Sensor
H: No paper exists.
L: Paper exists.
PAPER ROUTE:SUB Exit2 Sensor
H:No paper exists.
L:Paper exists.
TONER SENS K Toner Sensor
H: Blocked
L: Reflected
Y Toner Sensor
H: Blocked
L: Reflected
M Toner Sensor
H: Blocked
L: Reflected
C Toner Sensor
H: Blocked
L: Reflected
CVO FR TOP FU Front Cover Open Switch
H: Close
L: Open
Top Cover Open Switch *1
H: Close
L: Open
Faceup Cover Open
Switch
H:Close
L:Open
ST_FD Stack Full Sensor
H: No paper exists.
L: Paper exists.
REG L/R Color registration L Sensor
AD value:
**H
Color registration R Sensor
AD value:
**H
HT THERMISTER Upper Center Thermistor
AD value:
**H
Lower Thermistor
AD value:
**H
Upper Side Thermistor
AD value:
**H
Planar Heater Thermistor
AD value:
**H
HUM_TEMP_DEN Humidity Sensor
AD value:
**H
Temperature Sensor
AD value:
**H
Density Black Sensor
AD value:
**H
Density Color Sensor
AD value:
**H
BELT_LVPS Belt Thermistor
AD value:
**H
Low Volt Thermistor
AD value:
**H
ID UP/DOWN ID Up/Down Sensor
H: Up.
L: Down
1ST TAG 1st-TAG-K UID
UID:.
***H
1st-TAG-Y UID
UID:.
***H
1st-TAG-M UID
UID:.
***H
1st-TAG-C UID
UID:.
***H
2ND TAG 2nd-TAG-K UID
UID:.
***H
2nd-TAG-Y UID
UID:.
***H
2nd-TAG-M UID
UID:.
***H
2nd-TAG-C UID
UID:.
***H
F-RL FI Fuser release Sensor
H: ON
L: OFF
Fuser-In Sensor
H:ON.
L:OFF
MPT PE MPT Paper End Sensor
H: No paper exists.
L: Paper exists.
T1 PE TRAY1 Paper End Sensor
H: No paper exists.
L: Paper exists.
T1 HOP TRAY1 Hopping Sensor
H: No paper exists.
L: Paper exists.
T1 CASETTE SIZE Tray1 -PaperSize-1 Switch Port level H, L Tray1 -PaperSize-2 Switch Port level H, L Tray1 -PaperSize-3 Switch Port Level H, L Tray1 -PaperSize-4 Switch Port Level H, L
T2 PE TRAY2 Paper End Sensor
H: No paper exists.
L: Paper exists.
T2 HOP_LF_FED TRAY2 Hopping Sensor
H: No paper exists.
L: Paper exists.
TRAY2 Entrance Sensor
H: No paper exists.
L: Paper exists.
T2 CASETTE SIZE Tray2 -PaperSize-1 Switch Port level H, L Tray2 -PaperSize-2 Switch Port level H, L Tray2 -PaperSize-3 Switch Port Level H, L Tray2 -PaperSize-4 Switch Port Level H, L
T3 PE TRAY3 Paper End Sensor
H: No paper exists.
L: Paper exists.
T3 HOP _FED TRAY3 Hopping Sensor
H: No paper exists.
L: Paper exists.
TRAY3 Entrance Sensor
H: No paper exists.
L: Paper exists.
T3 CASETTE SIZE Tray3 -PaperSize-1 Switch Port level H, L Tray3 -PaperSize-2 Switch Port level H, L Tray3 -PaperSize-3 Switch Port Level H, L Tray3 -PaperSize-4 Switch Port Level H, L
