3. MAINTENANCE MENUS
Table 3-4
Panel display Driven unit Condition
ID MOTOR ID MOTOR
Low Volt Fan
ID motor Fan
Belt FAN
All ID(K/Y/M/C) are removed
BELT MOTOR Belt Motor
Low Volt Fan
ID Motor Fan
Belt FAN
All ID(K/Y/M/C) are removed
FUSER MOTOR Fuser Motor -
FUSER MTR REV Fuser Motor -
FUSER RLS Fuser Motor Fuser unit is installed
REGIST MOTOR Tray 1 Hopping Motor
Tray1 Registration Clutch
-
T1 HOPPING MOTOR Tray 1 Hopping Motor
Tray1 Registration Clutch
-
MPT MOTOR Tray 1 Hopping Motor
MPT Clutch
-
REGIST SHUTTER Color Registration Solenoid -
EXIT SOLENOID Duplex Solenoid Duplex unit is installed
DUPLEX MOTOR Duplex Motor Duplex unit is installed
DUPLEX CLUTCH Duplex Motor
Duplex Clutch
Duplex unit is installed
T2 HOPPING MOTOR Tray2 Hopping Motor
Tray2 Hopping Clutch
Tray2 is installed
T2 FEED CLUTCH Tray2 Hopping Motor
Tray2 Feed Clutch
Tray2 is installed
T3 HOPPING MOTOR Tray3 Hopping Motor
Tray3 Hopping Clutch
Tray3 is installed
T3 FEED CLUTCH Tray3 Hopping Motor
Tray3 Feed Clutch
Tray3 is installed
T4 HOPPING MOTOR Tray4 Hopping Motor
Tray4 Hopping Clutch
Tray4 is installed
T4 FEED CLUTCH Tray4 Hopping Motor
Tray4 Feed Clutch
Tray4 is installed
Panel display Driven unit Condition
2BIN SOLENOID Second Bin Solenoid Second Bin unit is installed
ID UP/DOWN Tray1 Hopping Motor
ID Lift-up clutch
TOP/FRONT Cover is closed
LV FAN TEST Low Volt Fan -
FUSER FAN TEST Fuser FAN -
FUSER2 FAN TEST Fuser side FAN -
DUPLEX FAN TEST Duplex Fan Duplex unit is installed
ID FAN TEST ID Motor Fan -
BELT FAN TEST Belt Fan -
Note! Display while ID UP/DOWN is in progress
MOTOR & CLTCH TEST
ID UP/DOWN ***
***: Identifies the number of times
Display when the REGIST SHUTTER [*] button is pressed
MOTOR & CLTCH TEST
SHT ***
***: Identifies the number of times
Display while FUSER RLS is in progress
MOTOR & CLTCH TEST
RLS ***
***: Identifies the number of times
