3. MAINTENANCE MENUS
Display Items of REG BELT REFLECT RESULT
Upper display Lower display Details Memory
L-SIDE= **
AV= ***
MAX=***
MIN=***
Upper display: Displays a test result on the left
side (OK or NG).
Displays the average of the sensor output ADC
scanning values [HEX]
Lower display: Displays the maximum or minimum
of the sensor output ADC scanning values [HEX]
SRAM
R-SIDE= **
AV= ***
MAX=***
MIN=***
Upper display: Displays a test result on the right
side (OK or NG).
Displays the average of the sensor output ADC
scanning values [HEX]
Lower display: Displays the maximum or minimum
of the sensor output ADC scanning values [HEX]
SRAM
• Results will be stored as described in memory filed.
• The contents in SRAM are deleted when the test starts, and values detected at the normal
competition or until the machine stops due to errors are written.
