45850101TH Rev.1
4-20
4.2.10.6 Hinge-Assy-L / Hinge-Assy-R
(1) Remove the ADF-unit and turn over it. (See the section 4.2.10.4)
(2) Remove the three screws (black, No:42932708)
①
and remove the hinge-
Assy-L
②
.
(3) Remove the three screws (black, No:42932708)
③
and remove the hinge-Assy-R
④
.
③
③
④
①
①
To Next Page
