4. REPLACEMENT OF PARTS
⑫
-1 Cover-Assy-TOP
⑫
-2 Cover-Assy-TOP
Plate-Assy.-Inner
Apply a normal amount of MOLYKOTE
(EM-30LP) to the hatched area
Class C
Apply a normal amount of MOLYKOTE
(EM-30LP) to the hatched area
Class C
Spring-Torsion
PM is applied to the portion of the slot of solidcoiling of
this torsion springs using a brush. (Left and Right both)
Class C
