4. REPLACEMENT OF PARTS
4.3.3 Scanner section
①
-1 Frame Assy.-FB
1) Plate-Pulley(Caulking)
Gear-Idle
Gear-Pulley
Without the internal perimeter
surface grease adhesion
㻌
HARVES MDF-1207
Apply HARVES all round.
HARVES MDF-1207
Apply HARVES all round.
HARVES MDF-1207
Apply HARVES all round.

Plate-Pulley(Caulking)
Gear-Pulley
Gear-Idle
