45850101TH Rev.1
5-8
(4) Separate the tabs on the roller guide from the left and right arms by
pushing the tabs to inside.
(5) Raise the roller guide until it comes in contact with the MFP.
(6) Wipe the two feed rollers with a tightly wrung cloth soaked in water through
the opening for MPT.
Note! 1. Use water only.
2. Do not bend the lever.
(7) Open the Retard Roller cover and wipe the retard roller with a tightly wrung
cloth soaked in water through the opening for MPT.
Note! 1. Use water only.
2. Do not bend the lever.
(8) Close the MPT is performed by the inverse procedure with opening.
To Next Page
