Oki MC873dn User Manual

Oki Data CONFIDENTIAL
45850101TH Rev.1
2-11
2. TROUBLESHOOTING PROCEDURES
No. Category PJL Status
Code
Panel messages Description
14 Warning 10970 (Y)
10971 (M)
10972 (C)
10969 (K)
%COLOR% Please
install new Image
Drum Unit.
Image Drum Life.
Press the [Details]
button for help.
Notifies the life of the drum. This is a warning
only.
This appears when the cover was opened and
closed just after the drum life error occurred.
%COLOR%
Y
M
C
K
15 Warning 10692 (Y)
10693 (M)
10694 (C)
10691 (K)
%COLOR%
Replace the image
drum. %PAGES%
Pages Left.
Press the [Details]
button for help.
Notifies the prolonged period of the image drum
life, after reached its limitation, by the operator's
requirement.
16 Warning 10686 (Y)
10687 (M)
10688 (C)
10685 (K)
%COLOR%
Replace the image
drum. Print Quality
Not Guaranteed.
Press the [Details]
button for help.
Notifies the last prolonged period of the image
drum life.
This appears after the hidden operation was done
at the life limitation.
17 Warning 10053 Belt Reflex Error Belt Reflex Check Error.
PU firmware does not notify this warning to CU
firmware at the time of Shipping Mode. Therefore,
this status does not occur in a user environment.
18 Warning 10887 Density Shutter
Error2
Density Adjustment Shutter Error 2.Error that
does not occur at user level.Displayed only in
FactoryMode.
PU firmware does not notify this warning to CU
firmware at the time of Shipping Mode. Therefore,
this status does not occur in a user environment.
19 Warning 10886 Density Shutter
Error1
Density Adjustment Shutter Error 1.Error that
does not occur at user level.Displayed only in
FactoryMode.
PU firmware does not notify this warning to CU
firmware at the time of Shipping Mode. Therefore,
this status does not occur in a user environment.
20 Warning 10885 Density Color
Calibration
Density Adjustment Color Calibration Error.Error
that does not occur at user level.Displayed only in
FactoryMode.
PU firmware does not notify this warning to CU
firmware at the time of Shipping Mode. Therefore,
this status does not occur in a user environment.
No. Category PJL Status
Code
Panel messages Description
21 Warning 10884 Density Color
Sensor Error
Density Adjustment Color Sensor Error.Error that
does not occur at user level.Displayed only in
FactoryMode.
PU firmware does not notify this warning to CU
firmware at the time of Shipping Mode. Therefore,
this status does not occur in a user environment.
22 Warning 10883 Density Black
Calibration
Density Adjustment Black Calibration Error.Error
that does not occur at user level.Displayed only in
FactoryMode.
PU firmware does not notify this warning to CU
firmware at the time of Shipping Mode. Therefore,
this status does not occur in a user environment.
23 Warning 10882 Density Black
Sensor Error
Density Adjustment Black Sensor Error.Error that
does not occur at user level.Displayed only in
FactoryMode.
PU firmware does not notify this warning to CU
firmware at the time of Shipping Mode. Therefore,
this status does not occur in a user environment.
24 Warning 10976 %COLOR% Image
Drum Smear Error
Density Adjustment ID ERROR 2; smear due to
ID failure.
PU firmware does not notify this warning to CU
firmware at the time of Shipping Mode. Therefore,
this status does not occur in a user environment.
%COLOR%
Y
M
C
K
25 Warning 10975 %COLOR% Low
Density Error
Density Adjustment ID ERROR; LED out of focus
is assumed.
PU firmware does not notify this warning to CU
firmware at the time of Shipping Mode. Therefore,
this status does not occur in a user environment.
%COLOR%
Y
M
C
K
26 Warning 10054 Sensor Calibration
Error
When output of color registration sensor is below
reference value.
PU firmware does not notify this warning to CU
firmware at the time of Shipping Mode. Therefore,
this status does not occur in a user environment.

Oki MC873dn Specifications

General

Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	9.5 s
Print speed (black, normal quality, A3)	20 ppm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 1200 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	10 s
Copy speed (black, normal quality, A4)	35 cpm
Scan to	CIFS, E-mail, FTP, HTTP, Image, USB
Scan drivers	TWAIN
Scanner type	ADF scanner
Output color depth	24 bit
Scan speed (color)	50 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 600 DPI
Faxing	Color faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	1000
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	75000 pages per month
Page description languages	Epson FX, IBM ProPrinter, PCL 5c, PCL 6, PDF 1.7, PostScript 3
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, EAP, SSL/TLS, WPA2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP, DHCP, DHCPv6, BOOTP, HTTP, HTTPS, DNS, DDNS, WINS, , UPNP, Bonjour, SNMPv1&v3, SNTP, IPP, IPPS, WSD Print, WSD Scan, LLTD, IEEE802.1X, LPR, Port9100, Telnet, FTP, IPSEC, SecureProtocolServer, LDAP, LDAPS, CIFS, FTP, FTPS, SMTP, SMTPS, POP3
Internal memory	1260 MB
Internal storage capacity	250 GB
Sound power level (standby)	37 dB
Sound pressure level (printing)	54 dB
Paper input type	Paper tray
Total input capacity	300 sheets
Maximum input capacity	400 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	100 sheets
Envelopes sizes	10, C4, C5, DL, Monarch
Custom media width	148.5 - 297 mm
Custom media length	210 - 431.8 mm
Paper tray media types	Banner, Envelopes, Plain paper
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	64 - 256 g/m²
Auto Document Feeder (ADF) media weight	60 - 120 g/m²
Display	LCD
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Standard interfaces	Ethernet, RJ-11, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	2
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1400 W
Power consumption (off)	0.1 W
Power consumption (sleep)	3 W
Power consumption (PowerSave)	30 W
Power consumption (average operating)	850 W
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	600 mm
Width	563 mm
Height	700 mm
