10-003591-01EN [Q7780031], Rev. 4, January 2020
Chapter 226
3. Set the indexing button’s encoder number (2), type (Clicker + Preset), and
origin (0):
a) Select Scan > Encoder > Encoder = 2.
b) Select Scan > Encoder > Type = Clicker + Preset.
c) Select Scan > Origin = 0.
The resolution value will be set as detailed in “Setting Up the Scan and Index
Parameters for an Elbow” on page 31.
4. Assign the digital input for the indexing button:
a) Select Preferences > Category = DIN.
b) Select Preferences > Select DIN = DIN 3 and set the state:
○ Select DIN3 > Assign DIN = Acquisition State.
○ Select DIN3 > State = On.
2.3 Installing the Probe and Wedge
Because of its design, the flexible phased array probe can be easily damaged if
handled incorrectly. It is not recommended to bring the probe into direct contact with
a part. The probe should only be shaped using an Olympus SFA1 type wedge.
Bending the probe too much could permanently damage it.
The flexible phased array probe slides into one of several available water wedge sizes
(see Figure 2-3 on page 27).
