10-003591-01EN [Q7780031], Rev. 4, January 2020
Chapter 658
6.2 Wedge Pipe Diameter Ranges
The FlexoFORM scanner’s wedges have predefined curvatures according to the
Nominal Pipe Size (NPS) standard. Although it is recommended to use a wedge that
matches the exact diameter of the inspected pipe, each wedge has a narrow range of
pipe diameters on which it can be used. Table 7 on page 59 provides the range of
coverage for each standard wedge diameter.
Magnetic field strength
of wheels
0.99 milligauss at a distance of 2.1 m (7 ft) from the wheels (below
the 2 milligauss limit at which restrictions would be imposed on
air shipment)
Encoder Recommended scanning speed: variable, dependent on OmniScan
instrument and application setup used.
Type: Quadrature
Resolution: 12 steps/mm ±0.15 steps/mm
Wet locations: Water resistant, IP55
Pinout: See Figure 6-1 on page 61
Voltage: 5 VDC
Maximum current: 100 mA
CLK frequency: 1 MHz
Environment
Outdoor use Yes
Altitude Up to 2000 m
Operating temperature 0 °C to 45 °C
Maximum inspection
surface temperature
100 °C (with water flow turned on)
Storage temperature −20 °C to 60 °C
Relative humidity (RH) N/A (water resistant; see IP rating below)
Pollution level 2
IP rating IP55
Table 6 General specifications (continued)
Parameter Value
